Description
- Hygro-thermostat for temperature monitoring and regulation in range 0 °C to 60 °C (32 °F to 140 °F) and relative humidity monitoring and regulation in range 50 to 90 %.
- Possibility of setting of up to 8 conditions for contact
- switching and function permanently ON/OFF.
Sensor is a part of the device – designated for measuring in switchboards. - Function of sensor control (damage, disturbances,…).
Fixed setting of temperature hysteresis at 2.5 °C (4.5 °F) - and humidity at 4 %.
Technical parameters
- Monitored temperature range: 0 to +60°C
- Monitored humidity range: 50 to 90°C
- Output: 1x NO, 16 A
- Housing: 1-MODULE
- Supply voltage (frequency): AC/DC 24-240 V (AC 50/60 Hz)
- Dimensions: 90 x 17.6 x 64 mm (3.5˝ x 0.7˝ x 2.5˝)
