- Relay is designed for monitoring levels in wells, basins, reservoirs, tanks,…
- In one device you can choose the following configurations:
- One-level switch of conductive liquids (by connecting H and D).
- Two-level switch of conductive liquids.
- One-state device monitors one level, two-state device monitors two levels (switches on one level and switches off on another level).
- Adjustable time delay on the output (0.5 – 10s).
- Sensitivity adjustable by a potentiometer (5 – 100).
- Measuring frequency 10 Hz prevents polarization of liquid and raising oxidation of measuring probes.
- Galvanically separated supply voltage UNI 24 to 240 V AC/DC.
Technical parameters
- Output: 1x CO, 8 A
- Sensitivity: 5-100 kohm
- Number of functions: 2
- Housing: 1-MODULE
- Supply voltage (frequency): 24-240 V AC/ DC (AC 50/60 Hz)
- Dimensions: 90 x 17.6 x 64 mm (3.5˝ x 0.7˝ x 2.5˝)
Download Datasheet
