Description
- Single thermostat for temperature monitoring and regulation in range 32 °F to 140 °F.
- It can be used for temperature monitoring e.g. in switchboards, heating systems, liquids, radiators, motors, devices, open spaces, etc.
- Fixed hysteresis at 1.8 °F.
- Sensor is a part of the device, monitoring switchboard temperature.
Technical parameters
- Monitored ranges: 32 °F to 140 °F
- Thermosensor type: built-in
- Output: 1x NO, 16 A
- Housing: 1-MODULE
- Supply voltage (frequency): AC/DC 24-240 V (AC 50/60 Hz)
- Dimensions: 3.5″ x 0.7″ x 2.5″
