Description
- Switching control based on measured temperature with built-in time switch allowing daily, weekly, and yearly programs. This way, the thermostat function can be limited in real-time as needed.
- The thermostat is subordinate to the time switch programs.
- Simple setting after the first start-up.
- Complex control of home and water heating, incl. solar heating.
- Two thermostats in one, two temperature inputs, 2-channel design (each with an operating hours counter).
- Functions: two independent single-stage thermostats, depending functions of two thermostats, differential thermostat, two-stage thermostat, thermostat with “WINDOW” function, thermostat with dead zone.
- Wide operating temperature settings –40 .. +120 °C (–40 .. +248 °F), that can be changed in real-time.
- A user-replaceable battery to back up the set time during power outages.
- Built-in web server for setup and control via Wi-Fi connection.
- Time synchronization through NTP server (require internet connection of thermostat).
- Possibility of permanent connection to the local network.
- WRC: web remote control and setup from anywhere (require internet connection of thermostat).
- New well-arranged display with white backlight.
- Pulse/cycle output mode.
- Transition of summer/winter time – AUTO or OFF.
- PIN code protection against unauthorized changes.
- Wireless firmware update – current version 1.22
Technical parameters
- Supply voltage: AC 100 − 240 V (50-60 Hz), DC 145 − 335 V
- Program: daily, weekly, yearly + temperature
- Replaceable battery: yes
- Sensor: external, NTC 12kΩ
- Temperature range: −40 .. +120 °C (–40 .. +248 °F)
- Wireless communication: Wi-Fi (2.4 GHz)
- Output: 2x changeover, 10 A (AgSnO2)
- Housing: 2-MODULE
- Dimensions: 3.5‘‘ × 1.4‘‘ × 2.5‘‘
